If you want to cut out an image in Illustrator or isolate part of the image, the easiest way you can do this is by creating a clipping mask around the parts you need to view. Below are the steps to follow.
- Step 1: Import the image to Illustrator
- Step 2: Lock the image
- Step 3: Create a Path
- Step 4: Unlock the image
- Step 5: Create Clipping Mask
- Step 6: Edit the Clipping Mask
- Step 7: Export image with a clear Background
Step 1: Import the image to Illustrator
Go to File>New and set size to create an artboard. Go to File>Place and navigate to where the image is saved. Alternatively, go File>Open then choose the image you want to edit.
Step 2: Lock the image
Select the image by clicking on it using the selection tool V. Click on shortcut keys Control+2 on PC or CMD+2 on Mac to lock the image. You can also go to Object>Lock>Selection.
Step 3: Create a Path
Use the Pen tool (P) to create a path around the area to cut out. Set fill to none and a thin stroke in a bright color. You have to know how to use the pen tool to do this.
You can fine-tune the shape using the Direct Selection Tool (A) tool and adjust anchor points and handles. If the cut out is a regular shape, just create the shape using the shape tools like ellipse, rectangles or any other.
Step 4: Unlock the image
You will notice the image is not selectable since it is locked. Click on shortcut keys Control+Alt+2 on PC or CMD+Opt+2 on Mac to unlock the image. You can also go to Object>UnLock All.
Step 5: Make Clipping Mask
Select the image and shape created by clicking Control+A on PC and CMD+A on MAC. Click Control+7 or CMD+7on MAC. You can also click Object>Clipping Mask>Make or Right-click and choose Make Clipping Mask. The areas covered by the shape are visible and those not are blocked out.
Step 6: Edit the Clipping Mask
To edit it, simply double click and drag the image or shape to the best position. You can also use the Direct Selection Tool to move points.
Step 7: Export with Transparent Background
Make sure the cut out image is on an artboard with no background. Go to File > Export > Export for Screens or Export As, choose PNG for transparent background. Make sure Use Artboards is checked if you want to limit export to the artboard.
Cut Out an Image in Illustrator: An Overview
- Step 1: Import the image to Illustrator
- Step 2: Lock the image
- Step 3: Create a Path
- Step 4: Unlock the image
- Step 5: Create Clipping Mask
- Step 6: Edit the Clipping Mask
- Step 7: Export image with a clear Background
